STAR PLUS System

The STAR Plus(tm) System adds the dimensions of ease of use, consistency of performance, and total system reliability to your product development and/or production program.

The Weiss Technik Star Plus System AGREE vibration chambers are equipped with an LN2 cooling system. The LN2 cooling system, with modulating valve and directed airflow to the product, provides the rapid thermal change rates required to achieve maximum product stress. Additionally, these rates are accomplished with smaller space requirements, lower audible noise, no water requirement, and lower maintenance costs than a typical refrigeration system.

The innovative WEBSeason® user interface allows you to program, control and monitor your tests at any time and anywhere – even from your tablet or smartphone

Specifications

Available in table sizes 44″ x 44″, 36″ x 36″ and 28″ x 28″
LN2 cooling system with modulating valve provides rapid thermal change rate (70˚C/min) for maximum product stress
Custom sizes available consult with your local salesperson
Many options available – contact your local salesperson for complete list

Product Features

Three-blower-wheel air circulation system provides enhanced airflow to the product for uniform temperature and greater consistency in testing
Stainless steel jack shafts withstand corrosive nature of the environment for a longer life
Nichrome wire heating elements with fail-safe fusible link eliminates the possibility of a “runaway” chamber
Solid-state heat switching eliminated the problem of worn out mechanical relay contactors
Stainless steel interior continuously heliarc welded to eliminate liner seam leakage for a longer lasting chamber
Chamber designed to keep the sound level of temperature/vibration testing below 78 dBa for a quiet, less disruptive performance in your lab or test area
Large, total-access doors make the full width and height of the workspace accessible
Touch screen commands
Independent Fuzzy Logic Parameters
Data Input Via Pop-up Displays
Set Point Versus Process Variable Displays
12 Event/Auxiliary Outputs
Selectable Inputs, T/C, RTD, Voltage, Current
Selectable Restart Modes After Power Failure
Quick Draw for Optimized Performance
Complete Diagnostics
Battery Backup
Optional Data Logging Capabilities up to 10 Channels

Technical Data
