Specifications
| Refrigeration Type | Air-Cooled | Water-Cooled | ||||||||||
| Model | ENDH-7 | ENDH-12 | ENDH-21 | ENDH-35 | ENDH-54 | ENDH-12/70 | ENDH-21/70 | ENDH-35/70 | ||||
| Test Space Volume (Cu. Ft./Liters) | 7/195 | 12/335 | 21/610 | 35/990 | 54/1540 | 12/335 | 21/610 | 35/990 | ||||
| Heating Rate (°C/min) | Up to 4 | Up to 3.2 | Up to 4 | Up to 4 | Up to 3.5 | Up to 5 | Up to 5 | Up to 5 | ||||
| Cooling Rate (°C/min) | Up to 3.5 | Up to 3.5 | Up to 3 | Up to 3 | Up to 2.5 | Up to 5 | Up to 5 | Up to 5 | ||||
| Temp Range (°C[°F]) | +180 to -40 (+356 to -40) | +180 to -70 (+356 to -94) | ||||||||||
| Humidity Range | 10% to 98% | |||||||||||
| External Width (inches[mm]) | 36″ (915) | 36″ (915) | 44.8″ (1138) | 56.1″ (1425) | 56.1″ (1425) | 36″ (915) | 44.8″ (1138) | 56.1″ (1425) | ||||
| External Depth (inches[mm]) | 59.7″ (1516) | 65.3″ (1660) | 66.7″ (1695) | 72.7″ (1847) | 93.4″ (2372) | 65.3″ (1660) | 66.7″ (1695) | 72.7″ (1847) | ||||
| External Height (inches[mm]) | 78.8″ (2002) | 78.8″ (2002) | 86.7″ (2202) | 86.7″ (2202) | 86.7″ (2202) | 78.8″ (2002) | 86.7″ (2202) | 86.7″ (2202) | ||||
