Specifications
- Sizes range from 36 to 72 cubic ft.
- Custom sizes can be tailored to specific project needs upon request.
IP ratings from the IEC 60529 and ISO 20653 standards are used to evaluate how well an enclosure is able to resist the entry of dust and liquids.
Our DustEvent test chambers are designed to conduct IP tests according to the necessary standards: DIN EN 60529 (IP5X / IP6X), ISO 20653 (IP5KX / IP6KX), and SAE J 575.
Additionally, with the right equipment, dust chambers can also meet other standards such as MIL STD 810 or EN 60068-2-68.
The Dust Test Chamber, D Series, is constructed of 16 gauge sheet metal with an air-dried lacquer-sprayed finish. The hinged lid provides full access to the workspace and is available with the option of viewing windows. In the larger D60 model, (2) 8″ to 10″ fan blades are mounted in the chamber to keep the dust in an agitated state. The pressure relief vent which is provided will prevent pressure buildup within the cabinet while preventing the escape of dust material.
